Application
The can drink filling production line is applicable for washing filling and capping all kinds of PET, aluminum, iron can.
This can drink filling production line can be used for filling cola, pure water, mineral water, carbonated drinks, tea drink, juice, hot drink and so on.
Washing, filling and capping could be automatically shifted.
It is ideal equipment for making tinned drinks.
Technical parameters
| Model |
JND 12-1 |
| Production capacity (CPH)(500ml) |
1000-2000 |
| Can dimension |
Diameter(50-80mm);Height(90-140mm) |
| Gas source pressure(Mpa) |
0.6 |
| Gas consumption(M3/Min) |
0.1 |
| Power(KW) |
3.2 |
| Model |
JND 18-6 |
| Production capacity (CPH)(500ml) |
5000-6000 |
| Can dimension |
Diameter(50-80mm);Height(90-140mm) |
| Gas source pressure(Mpa) |
0.6 |
| Gas consumption(M3/Min) |
0.2 |
| Power(KW) |
5.0 |
| Model |
JND 24-6 |
| Production capacity (CPH)(500ml) |
8000-12000 |
| Can dimension |
Diameter(50-80mm);Height(90-140mm) |
| Gas source pressure(Mpa) |
0.6 |
| Gas consumption(M3/Min) |
0.25 |
| Power(KW) |
6.0 |
| Model |
JND 32-8 |
| Production capacity (CPH)(500ml) |
18000-20000 |
| Can dimension |
Diameter(50-80mm); Height(90-140mm) |
| Gas source pressure(Mpa) |
0.6 |
| Gas consumption(M3/Min) |
0.3 |
| Power(KW) |
7.5 |
